Assembly 25: Staple finisher option 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8745 2 1 Sensor (throat media present) “Sensor (throat media present)
removal” on page 632
2 40X8742 2 2 Stapler tray spring “Stapler tray spring removal” on
page 639
3 40X8744 2 2 Stapler tray link assembly “Stapler tray link assembly removal”
on page 640
4 40X8721 2 2 Stapler option latch “Stapler option latch removal” on
page 638
5 40X8217 1 1 Sensor (bin full send) “Sensor (bin full send) removal” on
page 669
6 40X8226 1 1 Stapler spring with string “Stapler spring with string removal” on
page 637
7 40X8223 1 1 Stapler carriage assembly “Stapler carriage assembly removal”
on page 628
8 40X8225 1 1 Stapler door close limit switch “Stapler door close limit switch
removal” on page 626
9 40X7592 1 1 Sensor (cartridge door interlock) “Sensor (cartridge door interlock)
removal” on page 627
10 40X8216 1 1 Stapler right cover “Stapler right cover removal” on
page 624
11 40X8215 1 1 Stapler cartridge access door “Stapler cartridge access door
removal” on page 632
