Assembly 32: Staple, hole punch finisher option 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8741 1 1 Stapler drive gear assembly “Stapler drive gear assembly
removal” on page 755
2 40X7592 1 1 Sensor (HPU rear door interlock) “Sensor (HPU rear door
interlock) removal” on
page 776
3 40X8213 1 1 Stapler paddle motor “Stapler paddle motor
removal” on page 751
4 40X8739 1 1 Stapler main motor “Stapler main motor removal”
on page 750
5 40X8722 1 1 Stapler diverter plunger assembly “Stapler diverter plunger
assembly removal” on
page 754
6 40X7592 1 1 Sensor (paddle motor HP) “Sensor (paddle motor HP)
removal” on page 752
7 40X8740 1 1 Media pusher assembly “Media pusher assembly
removal” on page 759
8 40x8256 1 1 Stapler diverter motor “Stapler diverter motor
removal” on page 753
9 40X8721 2 2 Staple, hole punch latch “Staple, hole punch latch
removal” on page 749
10 40X8221 1 1 Stapler controller PCBA “Stapler controller PCBA
removal” on page 749
11 40X8224 1 1 Staple, hole punch lower interface cable “Staple, hole punch lower
interface cable removal” on
page 759
4063
Parts catalog
872
