15.3 Input lines
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
156
￭￭￭￭￭￭￭￭
900 Touch Control
Signal name Input signal Function
Sample ready ***1**** waits for a stepping pulse, of, for instance, a con-
nected Sample Processor, as soon as it is ready.
[New]
Add a new input signal to the list, see following chapter.
[Delete]
Delete the selected input signal from the list.
[Edit]
Edit the data of the selected input signal, see following chapter.
15.3.1 Editing the input signal
List of input signals: Input signal ▶ New / Edit
Signal name
Designation of the template.
Entry 24 characters maximum
Input signal
Entering the desired bit pattern:
Entering the bit pattern:
￭ 0 = line inactive
￭ 1 = line active
￭ * = retain line status
The input lines are always numbered from right to left, i.e. with the signal
*******1 line 0 is expected to be active.
NOTICE
We recommend masking lines that are of no interest or for which no
defined condition can be predicted with an asterisk (*).
Entry
Bit pattern of exactly 8 characters
Default value ********
