Metrohm 900 - Tubing Parameters

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8 Titrants
900 Touch Control
￭￭￭￭￭￭￭￭
55
8.5.2 Tubing parameters
Titrant: Edit ▶ Exchange unit ▶ Tubing param.
You can enter the length and diameter of the connected tubings in the
dialog Exchange unit / Tubing parameters. The values which have
already been entered correspond to the dimensions of the supplied stan-
dard tubings.
Dosing tip
Tubing to the dosing tip (9-2).
Length
Length of the tubing.
Input range 0.0 to 999.9 cm
Default value 40.0 cm
Diameter
Diameter of the tubing.
Input range 0.0 to 9.9 mm
Default value 2.0 mm
Dosing cylinder
Tubing to the dosing cylinder (9-3).
Length
Length of the tubing.
Input range 0.0 to 999.9 cm
Default value 13.0 cm
Diameter
Diameter of the tubing.
Input range 0.0 to 9.9 mm
Default value 2.0 mm
Reagent bottle
Tubing to the reagent bottle (9-1).
Length
Length of the tubing.
Input range 0.0 to 999.9 cm
Default value 25.0 cm
