Metrohm 900 - GLP Test for Exchange Unit and Dosing Unit; Figure 9 Exchange Unit - Tubing Connections

8.6 GLP test for exchange unit and dosing unit
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
56
￭￭￭￭￭￭￭￭
900 Touch Control
Diameter
Diameter of the tubing.
Input range 0.0 to 9.9 mm
Default value 2.0 mm
1
2
3
Figure 9 Exchange unit – tubing connections
1
Tubing to the reagent bottle
2
Tubing to the dosing tip
3
Tubing to the dosing cylinder
8.6 GLP test for exchange unit and dosing unit
Titrant: Edit ▶ Dosing unit / Exchange unit ▶ GLP test
In the dialog Exchange unit / GLP test or Dosing unit / GLP test,
respectively, you can define the time interval after which a GLP test must
be carried out again for the exchange unit or dosing unit.
GLP test date
Date on which the last GLP test was carried out.
Format: YYYY:MM:DD
