29 Parameters
900 Touch Control
￭￭￭￭￭￭￭￭
309
The values that are actually adjustable may vary from the values specified
here, depending on the hardware. The binding values can be found in the
Technical specifications chapter for the control instrument used.
Input range –1,250 to 1,250 mV (Increment: 25)
Default value 400 mV
Electrode check
on | off (Default value: off)
For the following electrodes, an electrode check can be carried out:
￭ pH electrodes
￭ Metal electrodes
￭ Ion-selective electrodes
A check is made that the electrode is properly connected and that no
short-circuit is present. The electrode check is carried out when this com-
mand is started. Note that this electrode check has nothing to do with the
electrode test (command ELT).
Temp. measurement
Type of temperature measurement.
Selection continuous | automatic | off
Default value automatic
continuous
A temperature sensor must be connected. The temperature is mea-
sured continuously.
automatic
If a temperature sensor is connected then the temperature will be mea-
sured continuously. Otherwise, the temperature entered manually will
be used (see dialog of the titration and measuring parameters).
off
The temperature will not be measured. The temperature entered man-
ually is used (see dialog of the titration and measuring parameters).
29.2.7 Dosing device
The parameters for the dosing device are edited under [Dosing device].
Dosing device
Selection of the MSB connector to which the dosing device is connected.
Every MSB connector will always be displayed.
Selection 1 | 2 | 3 | 4
Default value 1
