29.15 Dosing and Liquid Handling
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
460
￭￭￭￭￭￭￭￭
900 Touch Control
Output signal
This parameter can only be edited when a Remote Box is selected under
Interface.
Selection of the signal out of the templates or entering the required bit
pattern. Templates are defined under System ▶ Templates ▶ Output
lines.
NOTICE
A line set active is not being reset automatically, nor at the end of the
determination nor when the monitored quantity is in the range again.
Entering a bit pattern:
￭ 0 = line inactive
￭ 1 = line active
￭ * = retain line status
￭ p = set pulse
The output lines are always numbered from right to left, i.e. with the sig-
nal *************1 line 0 is set. With a pulse, the length is set to 200 ms.
If it is required to set pulses with other lengths, you have to define a corre-
sponding template.
Entry
Bit patterns containing exactly 14 characters
or a max. of 24 characters for the name of
the template
Default value **************
Selection Selection of the templates defined
Character string
This parameter can only be edited when a serial interface (COM) is
selected under Interface.
Input of the RS-232 command as character string. All characters of the
ASCII code page can be used. Control characters (Esc, FF etc.) have to be
entered as a three-place, decimal ASCII code, starting with a slash. Each
command is automatically terminated with the ASCII characters CR and
LF.
Entry ASCII string with a max. of 24 characters
Default value empty
