Equilibration
Equilibration is reached when the pressure change per equilibration time interval (first derivative) is
less than 0.01% of the average pressure during the interval. Both the first derivative and average pres-
sure are calculated using the Savitzky-Golay
1
convolution method for polynomial functions. The
following equations are those used to compute weighted average and first derivative, respectively, for
the 6th point of an 11-point window.
where the numerical constants are from the Savitzky-Golay convolution arrays, and
P
avg
= average pressure
P
chg
= change in pressure
P
pcp,i
= percent change per interval
P
i
=i
th
pressure reading taken at equilibrium intervals
P
avg
36 P
11
P
1
+–9P
10
P
2
+44 P
9
P
3
+69 P
8
P
4
+84 P
7
P
5
+89 P
6
++ + + +
429
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
=
P
chg
5 P
11
P
1
–4 P
10
P
2
–3 P
9
P
3
–2 P
8
P
4
–P
7
P
5
–+ +++
110
---------------------------------------------------------------------------------------------------------------------------------------------------------------
=
P
pcp i
100%
P
chg
P
avg
----------
=
If a non-zero value that is too small is entered for the maximum equilibration time, the
points are collected before equilibration is reached.
If P
avg
is greater than 0.995 times the current Po, equilibration will not take place until
the Minimum equilibration delay for P/Po 0.995 has expired, in addition to the standard
equilibration criteria.
