Defining Sample Information Files ASAP 2460 Operator’s Manual
2-12 246-42800-01 - Aug 2013
7. Click the dropdown arrows to select default parameter files for Degas conditions, Analysis
conditions, and Report options.
8. To auto-populate fields from another .SMP file, click the Replace All button and select a .SMP
file that contains the desired parameters. Select the file and click Replace.
9. Click the Add Log Entry button to enter notes for the instrument log report. Create entries that
cannot be recorded automatically through the application software. For example, you may record
that the port filter was changed.
10. Click Save, then click Close. The file can be retrieved later from the Sample Information folder in
the application Library.
Opening Sample Information Files
Columns in the File Selector window can be sorted by clicking the column header.
