Report Options Files ASAP 2460 Operator’s Manual
3-48 246-42800-01 - Aug 2013
f-Ratio Method
The f-Ratio report uses the measured isotherm and normalizes it using a reference isotherm. In the
Selected Reports list box, highlight f-Ratio Method, then click Edit.
Field or Button Description
Reference isotherm Click Browse to select a sample file to use as a reference for the isotherm.
Select a file containing an isotherm measured from a non-porous sample of
the same material as the current sample. When the referenced file is
selected, the file name appears to the left of the Browse button.
Tabular report
checkbox
Select to have a tabular report of data generated.
f-Plot checkbox Use to generate a normalized isotherm.
• Overlay samples checkbox - use to overlay sample files on the ï€
f-plot.
• Autoscale x-axis - the x-axis field is dimensionless in units of f-ratio.
• Autoscale y-axis - the y-axis field shows the quantity of gas adsorbed.
Pressures button Refer to Pressures button, page 3-30.
Browse button
Cancel button
From / To text boxes
OK button
Refer to Common Fields and Buttons - File Menu Options, page 3-1.
