ASAP 2460 Operator’s Manual Report Options Files
246-42800-01 - Aug 2013 3-47
Ref. surface area
ï€
text box
Enter the surface area from the reference curve. This value is used to
calculate the sample surface area.
Select Range for
Alpha-S Fit text boxes
Enter minimum and maximum relative pressures to determine the fit.
Tabular report
checkbox
Use to have a tabular report of data generated.
Alpha-S plot
ï€
checkbox
Use to plot data in graph format.
• Overlay samples checkbox - use to overlay sample files on the plot.
• Autoscale x-axis - the x-axis field shows the relative pressure.
• Autoscale y-axis - the y-axis field shows the quantity of gas adsorbed.
Pressures button Refer to Pressures button, page 3-30.
Browse button
Cancel button
From / To buttons
OK button
Save As button
Refer to Common Fields and Buttons - File Menu Options, page 3-1.
Field or Button Description (continued)
