Sample port connector For installing the sample tube.
P
o
port connector For installing a P
o
(saturation pressure) tube.
Turns on and flashes green while the analyzer is
attempting to communicate w
ith the computer. Once
communications are established, it remains solid green.
ASAP 2460 Operator’s Manual Controls, Indicators, and Connectors
246-42800-01 - Aug 2013 1-7
Side Panel
The side panel of the Master Unit contains the gas ports described below. Auxiliary units do not con-
tain gas ports.
Sample port
connector
P
o
port connector
Power
indicator
Analyzer power indicator
