Controls, Indicators, and Connectors ASAP 2460 Operator’s Manual
1-6 246-42800-01 - Aug 2013
The SmartPrep passes flowing-gas over the sample at elevated temperatures. It contains six sample
ports in which temperature, ramp rates, and soak times are individually controlled by the analysis
program so that all degas information is integrated into the sample data file for future reference.
The SmartPrep is the recommended degassing unit for the instrument.
• FlowPrep 060
The FlowPrep applies both heat and a stream of inert gas to the sample to remove adsorbed
contaminants from the surface and pores in preparation for analysis for up to 6 samples. It allows
you to manually choose the temperature, gas, and flow rate best suited for your sample material and
application.
The FlowPrep is an independent unit and not controlled by the analysis program.
•VacPrep 061
The VacPrep offers two methods for removing contaminants. In addition to flowing gas, it provides
vacuum to prepare samples by heating and evacuation of up to 6 samples. This combination allows
you to choose the preparation method that is best suited to your material or application. Needle
valves are also provided allowing you to introduce the vacuum slowly to prevent fluidization of
samples.
The VacPrep is an independent unit and not controlled by the analysis program.
Controls, Indicators, and Connectors
This section contains a description of the controls, indicators, and connectors located on the front and
side panels of the ASAP 2460 system.
Front Panel
The front panel of the Master Module and Auxiliary Modules contains analysis stations and saturation
pressure ports. The power indicator light is located in the left corner of the Master Module front panel.
