ASAP 2460 Operator’s Manual Report Options Files
246-42800-01 - Aug 2013 3-63
Dubinin Report Options
The Dubinin method provides pore volume distributions for microporous materials by making use of
an expression for the adsorption potential. In the Selected Reports list box, highlight Dubinin, then
click Edit.
Field or Button Description
Report Type
ï€
group box
Select report types. If Astakhov is selected, either select the Optimize
exponent checkbox or enter an appropriate exponent value in the text box.
Fitted Relative
Pressure Range
ï€
text boxes
Enter the minimum and maximum limits for Radushkevich or Astakhov
relative pressures included in the line fit.
Adsorptive button Displays the Adsorptive Options window. The recommended adsorptives
and their values are shown. Up to eight adsorptive and adsorbate property
factor combinations may be specified.
