ASAP 2460 Operator’s Manual Preventive Maintenance
246-42800-01 - Aug 2013 7-19
Testing the Analyzer for Leaks
Refer to Diagnostics, page 4-32.
Replacing the Vacuum Pump Exhaust Filter
The gases used by the analyzer are exhausted by vacuum pumps. An exhaust filter is installed on the
exhaust port of each oil-sealed vacuum pump. The filter minimizes the release of oil vapor and should
be replaced when it becomes so saturated with oil that it is ineffective.
This procedure applies to oil-based vacuum pumps only.
Exhaust filters are used on the vacuum pump to minimize the release of oil vapors.
The gases used are diluted substantially upon being released from the vacuum
pumps. However, it may be desirable in some locations to provide a fume hood for
added protection from hazardous gases and vapors released into the work area.
Vacuum pump
exhaust filter
To Next Page
