Minebea Intec PR5900 - Page 113

WP-A Max 3000g d= 0.1g
00
+
g
Calibration @admin
1
2
3
Max
Scale interval
Dead load at
Max at
calibrated at
Sensitivity
3000.0 g
0.1 g
mV/V
mV/V
µV/d
0.040750
1.00000
0.400000
30000 d
1 d
83.33 cnt/d
by load by mV/V by data Linear. Save
[by load] soft key
Calibrating with weights, see Chapter 4.7.1.2.1.4.1.
[by mV/V]soft key
Calibrating with mV/V values, see Chapter 4.7.1.2.1.4.2.
[by data] soft key
Calibrating with load cell data (smart calibration), see Chapter 4.7.1.2.1.4.3.
[Linear.] soft key
Calibrating with linearization points, see Chapter 4.7.1.2.1.4.4.
4.7.1.2.1.4.1 by load
In this menu item (under Max at), calibration of the Internal weighing point weighing
electronics is performed with weights.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [New] - [Max at] - [by load] .
WP-A Max 3000g d= 0.1g
00
+
g
Calibration @admin
1
2
3
Max
Scale interval
Dead load at
Max at
calibrated at
Sensitivity
3000.0 g
0.1 g
mV/V
mV/V
µV/d
0.040750
1.00000
0.400000
30000 d
1 d
83.33 cnt/d
by load by mV/V by data Linear. Save
Select [Max at] and press the corresponding soft key.
1. Select [Max at] and press the [by load] soft key.
An input window opens.
