[Range mode]
Selection: <Single range>, Multiple range, Multi-interval
For scale range selection, see Chapter 7.14.15.2 and 7.14.15.3.
Press the softkey to exit the menu and to save the settings.
7.14.15.1 Legal-for-trade mode
In the menu -[Weighing point]- [Calib]- [Param]- [W&M] you can choose between
[none] and the legal-for-trade modes [OIML], [NTEP], or[ NSC].
[none] [OIML] [NTEP] [ NSC]
Gross weight
display
B B G G
0.125 mV/V @
30,000 d
0.125 mV/V @
3000 e
0.125 mV/V @
3000 e
0.125 mV/V @
3000 e
0.25 mV/V @
60,000 d
0.25 mV/V @
6000 e
0.25 mV/V @
6000 e
0.25 mV/V @
6000 e
Recommended
min. measure-
ment signals
0.42 mV/V @
10,000 e
0.42 mV/V @
10,000 e
0.42 mV/V @
10,000 e
If legal-for-trade mode is switched on, the parameter settings (zero tracking etc.) must be
selected accordingly. The device does not peform a check of this.
The CAL switch (see Chapter 7.1.3.1) must be sealed in the closed position.
Note:
In the W&M mode an invalid weight without weight unit is shown.
7.14.15.2 Multiple range scale (Class III or single range scale Class I and II with variable scale interval)
The multiple range scale is a scale with two or more weighing ranges with dierent
maximum loads and scale intervals. There is only one load receptor, with each range
covering zero to its maximum load.
When [Range mode] = [Multiple range], the scale has up to three ranges with dierent
resolution.
The weight display header includes the current range (R1, R2, and R3), Max, Min, and d (or
e with instruments used in legal metrology) (example: multiple range scale in range 2):
The [Range limit 1] and [Range limit 2] switch points are the range limits.
As soon as the gross weight exceeds range 1, the next highest range with the next highest
scale interval becomes valid (1->2->5->10->20->50).
When reducing the weight, the interval of the previous range is kept. When the gross
weight is ≤0.25 d of range 1, the scale is stable and not tared, the scale returns to range 1
with the corresponding scale interval.
X3 Process Indicator PR 5410 7 Commissioning
Minebea Intec EN-176
