Note:
Some xBPI platforms have what is known as "specication blocks" for selecting
various modes of operation (single range, multiple range, etc.).
The following is required for the subsequent specication group selection:
- Note the model name of the scale.
- Refer to the operating instructions for the number of the corresponding
specication block.
Press [No] for exit from the menu without data change.
The parameters are listed as an overview in the following, see Chapter 7.15.5.1.
Note:
Only the parameters supported by the connected scale are displayed.
Press [No] for exit from the menu without data change.
The parameters are listed as an overview in the following, see Chapter 7.15.5.2.
Note:
Only the parameters supported by the connected scale are displayed.
Press [No] for exit from the menu without data change.
6. Select [Select group of specication] using the cursor and conrm.
7. Select and conrm the desired specication group.
8. Press the softkey to exit the menu and to save the settings.
A prompt window opens.
9. Press the [Yes] softkey to save the data.
The parameters are saved. Ticks indicate the progress.
10. Select [Conguration] using the cursor and conrm.
11. Select [Weighing parameters] with the cursor and conrm.
12. Press the softkey to exit the menu and to save the settings.
A prompt window opens.
13. Press the [Yes] softkey to save the data.
14. Select [Application settings] with the cursor and conrm.
15. Press the softkey to exit the menu and to save the settings.
A prompt window opens.
16. Press the [Yes] softkey to save the data.
17. Select [Interface settings] with the cursor and conrm.
7 Commissioning X3 Process Indicator PR 5410
EN-183 Minebea Intec
