Mobius AIRO Mobile CT System - Page 109

MI-42-0001 Rev. 19 97
SCANNING: Typical Scan Sequence: New Scan
Figure 67
Steps
1. Select main body region to be scanned (left column).
2. Select the protocol for the sub-region to be scanned (middle column).
3. Select scan type: Helical or Axial (right column).
4. Touch Next.
Options
To change the patient type or patient category, touch Back.
To proceed, touch Next.
