166 MI-42-0001 Rev. 19
MAINTENANCE: Cleaning, Disinfection, and Sterilization
Tilting the Ring for
Cleaning
The Ring may be tilted in Hospital Service mode to allow cleaning access to all parts of the system.
Figure 135
Figure 136
Figure 137
Steps
1. Decide in which direction the Ring needs to tilt and ensure there are no objects or obstacles
in the way.
NOTE: The Ring can be tilted up to 90° from the vertical, homed position in either direction.
2. Unscrew and retain the Tilt Stop
a
on the side of the Ring that will rise during the tilt.
3. On the Pendant, enter Hospital Service (see section 7.2 Service Functions).
