48 MI-42-0001 Rev. 19
TRANSPORT MODE: Transportation
Ring is not latched
in one or both
orientations
1. Latch the Ring in Scan position.
NOTE: This is to keep the Ring from turning while you
push it.
3.3.6
2. Make sure there is room for the Ring to rotate.
3. From the Choose Mode screen, select
Transport
.
The screen shows instructions for latching the Ring into
the Transport position. See Figure 24.
4. Unlatch the Ring and follow the on-screen instructions.
Make sure that the Ring latches:
• In line with the base.
• In the middle of the base’s Z-axis.
For more information, see section 3.3.5 Starting from
Scan Mode.
Move the Ring slowly and carefully. Moving the Ring
quickly can damage the anchor points in the Ring and
Transport latches.
See cautions about rotating the Ring in section
3.3.6 Rotating and Latching the Ring in Transport or
Scan Position.
Base is on the floor,
casters stowed
System prompts you to raise the system. 3.3.7
Universal Option
At any time, touch
Menu
and select Home from the dialog to return to the Choose
Mode screen. See section 3.3.4 Menu in Transport Mode.
Optional
Conditions
Steps See
To Next Page
