Table 7-27 Screen Elements of Shuto-Nozzle Settings
Screen Element Descripon
Without Sensors
Only the Output indicators are shown.
Movement Conditions
The shuto nozzle will only operate if certain
conditions are met.
The barrel heats must be up to temperature
and auto-soak completed successfully or the
soak timer must be nished.
The shuto nozzle cannot be operated
manually when the system is in automatic
mode.
The servo motors must be on (F10 LED on).
7-47
© 2020 Mold-Masters (2007) Limited. All Rights Reserved.
E-MULTI CONTROLLER HMI INTERFACE
E-Multi Controller User Manual
