Mold-Masters E-Multi EM1 - Page 102

Table 7-28 Screen Elements of Shuto󰀨 Nozzle Settings
Screen Element Descripon
Open Trigger
Selects the open trigger for the shuto󰀨
nozzle.
Mold Close—The shuto󰀨 nozzle
opens when the Mold Close (A6) signal
from the IMM turns on.
Remote Trigger—The shuto󰀨 opens
when the Remote Trigger signal from
the IMM turns on.
Before Injection—The shuto󰀨 opens
when the injection trigger specied on
the E67 settings page turns on.
Always Open—The shuto󰀨 nozzle
stays open except when the safety
gate is opened, an emergency stop
condition is present, or the system is
turned o󰀨.
Open Trigger—IMM Position
The shoto󰀨 nozzle opens when the
IMM screw position falls below the
Position setpoint.
The eld with the gray background
displays the IMM position in real time.
Delay—Open
Adds a delay of the specied time after
the open trigger turns on.
Delay time is ignored if the shuto󰀨
nozzle is set to Always Open.
7-49
© 2020 Mold-Masters (2007) Limited. All Rights Reserved.
E-MULTI CONTROLLER HMI INTERFACE
E-Multi Controller User Manual
