Table 7-28 Screen Elements of Shuto󰀨 Nozzle Settings
Screen Element Descripon
Close Trigger
The shuto󰀨 nozzle closes automatically
after pre-decompression (also known
as decompression before plasticize)
completes.
The indicator turns on when pre-
decompression completes.
Delay—Close
Adds a delay of the specied time after
the pre-decompression is complete.
If a recovery delay is used the recovery
delay is added after this delay.
Delay time is ignored if the shuto󰀨
nozzle is set to Always Open.
7-50
