NICE1000
new
User Manual Description of Function Codes
- 123 -
40: Motor overheat signal
If this signal remains active for more than 2s, the controller stops output and reports fault
Err39 to prompt motor overheat.
41: Door machine 1 safety edge signal 42: Door machine 2 safety edge signal
They are used to detect the safety edge signal state of door machine 1 and door machine 2
(if existing).
43: Earthquake signal
If this signal remains active for more than 2s, the elevator enters the earthquake stop state,
stops at the nearest landing oor and opens the door. Then the elevator starts running again
after the earthquake signal becomes inactive.
44: Back door forbidden signal
If double door machines are applied, this signal is used to prohibit the use of door machine
2.
45: Light-load signal
It is used for nuisance judgment in the anti-nuisance function. If Bit2 in F8-13 is set to 1, the
system performs nuisance judgment by using the light-load switch. The load below 30% of
the rated load is regarded as light load.
46: Single/Double door selection
This function is valid only in opposite door control mode 3. When this signal is active, the
elevator is double door service state; otherwise, the elevator is in single door service state.
47: Fire emergency oor switchover signal
The NICE1000
new
supports two re emergency oors. By default, the elevator stops at re
emergency oor 1 in re emergency state. If this signal is active, the elevator stops at re
emergency oor 2 in re emergency state.
48: Virtual oor input
This signal is required when the oor distance is too large.
If the oor distance is too large, the time protection may be enabled and the system reports
Err30 after a long-time running. To solve the problem, you need to set the virtual oor input
at a proper intermediate position of the oor. Then, the elevator clears the counted time after
arriving at this virtual oor, so that the system will not report Err30.
49: Fireghter switch signal
It is the firefighter switch signal and is used to enable the firefighter running. After the
elevator returns to the re emergency oor, the elevator enters the reghter running state if
the reghter signal is active.
51–99: Reserved
101–199: These signals respectively correspond to 01 to 99 in sequence. 01 to 99 are NO
inputs, while 101 to 199 are NC inputs.
