Page #122 background image
Description of Function Codes NICE1000
new
User Manual
- 120 -
Group F5: Input Terminal Parameters
Function Code Parameter Name Setting Range Default Unit Property
F5-00
Attendant/Automatic
switchover time
3–200 3 s
If there is a hall call at current oor in attendant state, the system automatically switches
over to the automatic (normal) state after the time set in this parameter. After this running is
completed, the system automatically restores to the attendant state (Bit2 of F6-67 must be
set to 1). When the value of this parameter is smaller than 5, this function is disabled, and
the system is in the normal attendant state.
Function Code Parameter Name Setting Range Default Unit Property
F5-01 X1 function selection
0–127
33 -
F5-02 X2 function selection 104 -
F5-03 X3 function selection 105 -
···
F5-23 X23 function selection 00 -
F5-24 X24 function selection 00 -
These parameters are used to set the functions of input terminals X1 to X24.
Terminals X1 to X24 are digital inputs, and are allocated with corresponding functions based
on the input signals. The same function must not be allocated to multiple terminals. After the
24 V voltage is input, the corresponding input terminal indicator becomes ON. The functions
are described as follows:
00: Invalid
Even if there is signal input to the terminal, the system has no response. You can allocate
this function to terminals that are not used to prevent mis-function.
01: Leveling 1 signal 02: Leveling 2 signal
03: Door zone signal
The NICE1000
new
system determines the elevator leveling position based on the leveling
sensor signal. The system supports three types of leveling configuration: a. single door
zone sensor; b. up and down leveling sensors; c. door zone sensor + up and down leveling
sensor.
If the leveling signal is abnormal (stuck or unavailable), the system reports fault Err22.
04: RUN contactor feedback signal 05: Brake contactor feedback signal 1
06: Brake travel switch feedback signal 1 50: Brake travel switch feedback signal 2
The system detects the feedback from the RUN and brake contactors 2s after outputting the
contactor RUN signal, to determine whether the related contactor is closed properly.
07: Shorting PMSM stator contactor feedback signal
When the elevator enters emergency running state upon power failure, the brake is released
and the related terminal outputs the signal if the motor is PMSM and is in automatic
emergency running state. The car automatically moves to the nearest leveling position
