- 143 -
It is used to set the blinking advance time when the elevator arrives the oor required by the
car call.
Function Code Parameter Name Setting Range Default Unit Property
F6-75
Waiting time for switchover from
shorting stator braking mode to
controller drive
0.0–45.0 20.0 s
☆
It is used to set the interval for switchover from shorting stator braking mode to controller
drive mode. If the elevator does not reach the leveling position with the time set in this
parameter, the system switches over to the controller drive mode for emergency evacuation.
Group F7: Output Terminal Parameters
Function Code Parameter Name Setting Range Default Unit Property
F7-00 Y0 function selection 00–05 or 32 00 -
★
As an independent relay output, Y0 can be allocated with any function among all the relay
output functions. When function 32 "emergency evacuation at power failure" is required,
only Y0 can be used as the relay for this output. F7-00 must be set to 32 so that the elevator
can switch over to the emergency evacuation state after power failure.
Function Code Parameter Name Setting Range Default Unit Property
F7-01 Y1 function selection 00–05 01 -
★
F7-02 Y2 function selection 00–05 02 -
★
F7-03 Y3 function selection 00–05 04 -
★
The functions that can be allocated for F1-01 to F7-03 are as follows:
•
00: Invalid
The terminal has no function.
•
01: RUN contactor output
The terminal with this function controls whether the RUN contactor is opened or closed.
•
02: Brake contactor control
The terminal with this function controls whether the brake contactor is opened or closed.
•
03: Higher-voltage startup of brake
The terminal retains the output for continuous 4s to control startup of the brake.
•
04: Lamp/Fan running
It is used for the lamp/fan running output.
•
05: Shorting PMSM stator contactor
When the elevator enters emergency running state upon power failure, the brake
is released and this signal is output. The car automatically moves to the nearest
