NICE1000
new
User Manual Description of Function Codes
- 165 -
located when the fault occurs, and the two low digits indicate the fault code. For example,
the 1st fault code is 0835, indicating that when the 1st fault (fault Err35) occurs, the car is
near oor 8.
The fault subcode is used to locate the causes of the fault. The specific fault time is
recorded in month, day, hour and minute.
Function Code Parameter Name Setting Range Default Unit Property
FC-36 Latest fault code 0–9999 0 -
FC-37 Latest fault subcode 0–65535 0 -
FC-38 Logic information of latest fault 0–65535 0 -
FC-39 Curve information of latest fault 0–65535 0 -
FC-40 Set speed upon latest fault 0.000–1.750 0 m/s
FC-41
Feedback speed upon latest
fault
0.000–1.750 0 m/s
FC-42 Bus voltage upon latest fault 0.0–999.9 0 V
FC-43 Current position upon latest fault 0.0–300.0 0 m
FC-44 Output current upon latest fault 0–999.9 0 A
FC-45
Output frequency upon latest
fault
0.00–99.99 0 Hz
FC-46 Torque current upon latest fault 0.0–999.9 0 A
Group Fd: Communication Parameters
Function Code Parameter Name Setting Range Default Unit Property
Fd-00 Local address
0–127
0: Broadcast address
1 -
Fd-01
Communication
response delay
0–20 10 ms
Fd-02
Communication
timeout
0.0–60.0
0: Invalid
0.0 s
These RS232 serial port communication parameters are used for communication with the
monitor software in the host computer.
Fd-00 species the current address of the controller. The setting of these two parameters
must be consistent with the setting of the serial port parameters on the host computer.
Fd-01 species the delay for the controller to send data by means of the serial port.
Fd-02 specifies the communication timeout time of the serial port. Transmission of
each frame must be completed within the time set in this parameter; otherwise, a
communication fault occurs.
