Description of Function Codes NICE1000
new
User Manual
- 154 -
Function Code Parameter Name Setting Range Default Unit Property
FA-13 Curve information 0–65535 0 -
It displays the system running curve information. Similar to the display of FA-12, LEDs 5, 4
and 3 have no display, while LEDs 2 and 1 show the running curve information.
LED 5 LED 4 LED 3 LED 2 LED 1
No
Display
No
Display
No
Display
Curve Information
- - -
00 Standby state 09 Deceleration start segment
01
Zero-speed start
segment
10
Linear deceleration
segment
02
Zero-speed holding
segment
11 Deceleration end segment
03 Reserved 12 Zero speed at stop
04 Startup speed stage 13 Current stop phase
05
Acceleration start
segment
14 Reserved
06
Linear acceleration
segment
15 Stop data processing
07
Acceleration end
segment
16-20 Auto-tuning stage
08
Stable-speed running
segment
21 Emergency operation
Function Code Parameter Name Setting Range Default Unit Property
FA-14 Set speed 0.000–4.000 0 m/s
FA-15 Feedback speed 0.000–4.000 0 m/s
FA-16 Bus voltage 0–999.9 0 V
FA-17 Present position 0.00–300.0 0 m
FA-18 Output current 0.0–999.9 0 A
FA-19 Output frequency 0.00–99.99 0 Hz
FA-20 Torque current 0.0–999.9 0 A
FA-21 Output voltage 0–999.9 0 V
FA-22 Output torque 0–200.0 0 %
FA-23 Output power 0.00–99.99 0 kW
These parameters display the current performance state of the system (the output torque
and output power supports positive/negative display).
Function Code Parameter Name Setting Range Default Unit Property
FA-24 Communication interference 0–65535 0 -
