Page #29 background imageLoading...
Page #29 background image
Product Information NICE1000
new
User Manual
- 28 -
The following table lists the mounting dimensions of different models.
Table 2-3 Mounting dimensions of the NICE1000
new
Controller Model
A
(mm)
B
(mm)
H
(mm)
W (mm)
D
(mm)
Hole
Diameter
(mm)
Gross
Weight
(kg)
Single-phase/Three-phase 220 V, range: -15% to 20%
NICE-L-H-2002
150 334.5 347 223 143 6.5 5.5
NICE-L-H-2003
220-NICE-L-H-4007
150 334.5 347 223 173.5 6.5 7220-NICE-L-H-4011
220-NICE-L-H-4015
220-NICE-L-H-4018
195 335 350 210 192 6 9.1
220-NICE-L-H-4022
220-NICE-L-H-4030 230 380 400 250 220 7 17
Three-phase 380 V, range: -15% to 20%
NICE-L-H-4002
150 334.5 347 223 143 6.5 5.5NICE-L-H-4003
NICE-L-H-4005
NICE-L -H-4007
150 334.5 347 223 173.5 6.5 7NICE-L -H-4011
NICE-L -H-4015
NICE-L-H-4018
195 335 350 210 192 6 9.1
NICE-L-H-4022
NICE-L-H-4030
230 380 400 250 220 7 17
NICE-L-H-4037
NICE-L-H-4045
260 580 600 385 265 10 32
NICE-L-H-4055
2.6 Optional Parts
If any optional part in the following table is required, specify it in your order.
Table 2-4 Optional parts of the NICE1000
new
Name Model Function Remark
External
braking unit
MDBUN
It is provided for the NICE1000new of
37 kW and above.
For details, see section
2.7 "Selection of Braking
Components".
Energy
feedback
unit
MCTC-
AFE
It is used for energy saving. This unit
feeds back the electricity generated
during braking to the grid.
-
