System Commissioning and
Application Example NICE1000
new
User
Manual
- 72 -
■
Emergency
ARD Power Supply
The
ARD is a emergency evacuation device with the self recognition and control functions.
It is connected between the mains supply and the elevator control cabinet. When the mains
supply is normal, it supplies power to the elevator
. When the mains supply is interrupted, the
ARD supplies power to the main circuit and control circuit.
The following gure shows the schematic diagram.
Figure 5-9 Three-phase emergency
ARD power supply
L1
L2
L3
R
Power
distribution
box
X19
24V
S
T
R
S
T
R
Elevator control cabinet
Emergency
evacuation
signal output
Phase shorting
output
11
14
ARD for
emergency leveling
at power failure
Phase relay
L1
L2
S
T
1
2
3
4
L3
NICE1000
new
Safety circuit 110 V
ARD
11
14
X25 MCB
Emergency
feedback 24 V
ARD
1
2
X19 MCB
3
4
Phase relay
Figure 5-10 Single-phase emergency
ARD power supply
L1
N1
L0
Power
distribution
box
X19
24V
S
R
S
T
R
Elevator control cabinet
Emergency
evacuation
signal output
ARD for
emergency leveling
at power failure
NICE1000
new
L1
N1
N0
1
2
Emergency
feedback 24 V
ARD
1
2
X19 MCB
73
75
