Mechanical and Electrical Installation NICE1000
new
User Manual
- 40 -
3.3.2 Description of the MCTC-KZ-D Extension Card
The extension card is mainly used for extension of oor button inputs and relay outputs.
1
.
Installation method and dimensions
The following figure shows installation of the MCTC-KZ-D. The CN2 interface of the
MCTC-KZ-D is connected to the CN5 interface on the MCB of the NICE1000
new
by using a
connection cable.
Figure 3-6 Appearance and installation of the MCTC-KZ-D
MCTC-KZ-D
CN2
CN3 CN4
CN1
CN5
Connection cable
Figure 3-7 Mounting dimensions of the MCTC-KZ-D
MCTC-KZ-D
CN2
CN3
L31
L32
L33
L34
L35
L36
L37
L38
L41
L42
L43
L44
L
45
L46
L47
L48
L49
L39
L40
L50
79
130
70
121
L30
L29
L
28
L27
CN4
YM
Y27
Y26
Y25
Y24
Y23
Y5
Y4
CN1
L27
L28 L29
L30 L31 L32 L33 L34
L35
L36
L37
L38 L39 L40 L41 L42
L43 L44 L45 L46
L47 L48
L49 L50
Y27
Y26
Y25
Y24
Y23
Y4
Y3
Unit: mm
2. Function description of terminals
Table 3-4 Function description of terminals
Mark Code Terminal Name Function Description Terminal Arrangement
CN3 L27 to L38
Button function
selection
Button input and button
indicator output,
24 V power for button
illumination
CN3
L37
L36
L35
L34
L
33
L
32
L31
L30
L29
L28
L27
L38
L48
L47
L46
L45
L44
L43
L42
L41
L40
CN
4
L50
L49
L39
CN4 L39 to L50
Button function
selection
Button input and button
indicator output,
24 V power for button
illumination
