Monarch NICE1000 User Manual

Description of Function Codes NICE1000
new
User Manual
- 168 -
Bit Parameter of Output Y Bit Parameter of Output Y
Low Bit0
10: Low 7-segment a display
output
Low Bit3
13: Low 7-segment d display
output
Low Bit1
11: Low 7-segment b display
output
High bits
28: High bit output of BCD/
Gray/7-segment code
Low Bit2
12: Low 7-segment c display
output
- -
Binary code: A Y output controls a display bit. In the NICE1000
new
, the output parameter of
each display bit is based on the parameter setting of 7-segment code, as described in the
following table.
Bit Parameter of Output Y Bit Parameter of Output Y
Bit0 10: Low 7-segment a display output Bit3 13: Low 7-segment d display output
Bit1 11: Low 7-segment b display output Bit4 14: Low 7-segment e display output
Bit2 12: Low 7-segment c display output - -
One to one output: A Y output is used for the display of each oor. In the NICE1000
new
, the
output parameter of each oor display is based on the parameter setting of 7-segment code,
as described in the following table.
Floor Parameter of Output Y Floor Parameter of Output Y
1 10: Low 7-segment a display output 9 42: High 7-segment b display output
2 11: Low 7-segment b display output 10 43: High 7-segment c display output
3 12: Low 7-segment c display output 11 44: High 7-segment d display output
4 13: Low 7-segment d display output 12 45: High 7-segment e display output
5 14: Low 7-segment e display output 13 46: High 7-segment f display output
6 15: Low 7-segment f display output 14 47: High 7-segment g display output
7 16: Low 7-segment g display output 15 19: Minus sign display output
8 41: High 7-segment a display output 16
28: High bit output of BCD/Gray/
7-segment code
Function Code Parameter Name Setting Range Default Unit Property
FE-13 Elevator function selection 1 0–65535 0 -
☆
Each bit of the function code denes a function, as described in the following table.
If a bit is set to 1, the function indicated by this bit is enabled; if this bit is set to 0, the
function is disabled.
For details on how to view and set this function code in bit, refer to F6-06.
