Monarch NICE1000 User Manual

NICE1000
new
User Manual Description of Function Codes
- 167 -
Function
Code
Parameter
Name
Setting Range Default Unit Property
FE-01 Floor 1 display
The two high digits
indicate the display
code of the ten’s
digit, and the two
low digits indicate
the display code of
the unit’s digit.
00: Display "0"
01: Display "1"
02: Display "2"
03: Display "3"
04: Display "4"
05: Display "5"
06: Display "6"
07: Display "7"
08: Display "8"
09: Display "9"
10: Display "A"
11: Reserved
12: Reserved
13: Display "H"
14: Display "L"
15: Reserved
16: Display "P"
17: Reserved
18: Display "-"
19: No display
23: Display "C"
24: Display "d"
25: Display "E"
26: Display "F"
28: Display "J"
31: Display "o"
35: Display "U"
1901 -
☆
FE-02 Floor 2 display 1902 -
☆
FE-03 Floor 3 display 1903 -
☆
FE-04 Floor 4 display 1904 -
☆
FE-05 Floor 5 display 1905 -
☆
Floor 6 to oor 10 display ···
FE-11 Floor 11 display 0101 -
☆
FE-15 Floor 12 display 0102 -
☆
FE-16 Floor 13 display 0103 -
☆
FE-17 Floor 14 display 0104 -
☆
FE-18 Floor 15 display 0105 -
☆
FE-19 Floor 16 display 0106 -
☆
These parameters are used to set the display of each oor. The setting range is 0000–9999,
where the two high digits indicate the display code of the ten's digit, and the two low digits
indicate the display code of the unit's digit.
Function
Code
Parameter Name Setting Range Default Unit Property
FE-12
Hall call output
selection
0–4 1 -
☆
It is used to set the coding method of the hall display board. By default, the system uses the
BCD code.
•
0: 7-segment code
•
1: BCD code
•
2: Gray code
•
3: Binary code
•
4: One-to-one output
7-segment code: For the output setting, see the description in Group F7.
BCB/Gray code: A Y output controls a display bit. In the NICE1000
new
, the output parameter
of each display bit is based on the parameter setting of 7-segment code, as described in the
following table.
