Product Information NICE1000
new
User Manual
- 30 -
Table 2-5 Braking resistor selection for the NICE1000
new
models
Controller Model
Power of
Adaptable
Motor (kW)
Max.
Resistance
(Ω)
Min.
Resistance
(Ω)
Power of
Braking
Resistor (W)
Braking Unit
Single-phase 220 V, range: -15% to 20%
NICE-L-H-2002 1.1 145.0 125.0 300
Built-in
NICE-L-H-2003 1.5 105.0 90.0 450
220-NICE-L-H-4007 2.2 72.0 63.0 600
220-NICE-L-H-4011 3.7 43.0 37.0 1100
220-NICE-L-H-4015 4.0 40.0 35.0 1200
220-NICE-L-H-4018 5.5 29.0 25.0 1600
220-NICE-L-H-4022 11.0 18.0 16.0 3500
Built-in
220-NICE-L-H-4030 15.0 13.0 13.0 4500
Three-phase 220 V, range: -15% to 20%
NICE-L-H-2002 2.2 72.0 65.0 600
Built-in
NICE-L-H-2003 3.7 54.0 50.0 1100
220-NICE-L-H-4007 4.0 40.0 35.0 1200
220-NICE-L-H-4011 5.5 29.0 25.0 1600
220-NICE-L-H-4015 7.5 26.0 22.0 2500
220-NICE-L-H-4018 11.0 14.5 13.0 3500
220-NICE-L-H-4022 15.0 13.0 12.5 4500
220-NICE-L-H-4030 18.5 12.5 12.0 5500
Three-phase 380 V, range: -15% to 20%
NICE-L-H-4002 2.2 290 230 600
Built-in
NICE-L-H-4003 3.7 170 135 1100
NICE-L-H-4005 5.5 115 90 1600
NICE-L-H-4007 7.5 85 65 2500
NICE-L-H-4011 11 55 43 3500
NICE-L-H-4015 15 43 35 4500
NICE-L-H-4018 18.5 34.0 25 5500
NICE-L-H-4022 22 24 22 6500
NICE-L-H-4030 30 20 16 9000
NICE-L-H-4037 37 16.0 13 11000 MDBUN-60-T
NICE-L-H-4045 45 14.0 11 13500 MDBUN-60-T
NICE-L-H-4055 55 12.0 10 16500 MDBUN-90-T
