Description of Function Codes NICE1000
new
User Manual
- 130 -
No. Segment Meaning of Segment ON
4
A Floor 5 door 2 up call I/O active
B Floor 5 door 2 down call I/O active
C Floor 6 door 2 up call I/O active
D Floor 6 door 1 down call I/O active
E Floor 7 door 1 up call I/O active
F Floor 7 door 1 down call I/O active
G Floor 8 door 1 up call I/O active
DP Floor 8 door 1 down call I/O active
5
A Floor 9 door 1 up call I/O active
B Floor 9 door 1 down call I/O active
C Reserved
D Floor 10 door 1 down call I/O active
E Reserved
F Reserved
G Reserved
DP Reserved
Group F6: Basic Elevator Parameters
Function Code Parameter Name Setting Range Default Unit Property
F6-00 Top oor of the elevator F6-01 to 16 5 -
F6-01 Bottom oor of the elevator 1 to F6-00 1 -
These two parameters are used to set the top floor and bottom floor of the elevator,
determined by the number of actually installed leveling plates.
Function Code Parameter Name Setting Range Default Unit Property
F6-02 Parking oor F6-01 to F6-00 1 -
When the idle time of the elevator exceeds the value set in F9-00, the elevator returns to the
parking oor automatically.
Function Code Parameter Name Setting Range Default Unit Property
F6-03 Fire emergency oor F6-01 to F6-00 1 -
When entering the state of returning to the re emergency oor, the elevator returns to this
oor.
Function Code Parameter Name Setting Range Default Unit Property
F6-04 Elevator lock oor F6-01 to F6-00 1 -
When entering the elevator lock state, the elevator returns to this oor.
