- 80 -
Chapter 6 Function Code Table
6.1 Function Code Description
1. There are a total of 17 function code groups, each of which includes several function
codes. The function codes adopt the three-level menu. The function code group number
is Level-I menu; the function code number is Level-II menu; the function code setting is
Level-III menu.
2. The meaning of each column in the function code table is as follows:
Function Code Indicates the function code number.
Parameter Name
Indicates the parameter name of the function
code.
Setting Range Indicates the setting range of the parameter.
Default
Indicates the default setting of the parameter at
factory.
Unit Indicates the measurement unit of the parameter.
Property
Indicates whether the parameter can be modied
(including the modication conditions)
The modication property of the parameters includes three types, described as follows:
"
☆
": The parameter can be modied when the controller is in either stop or running state.
"
★
": The parameter cannot be modied when the controller is in the running state.
"
●
": The parameter is the actually measured value and cannot be modied.
The system automatically restricts the modification property of all parameters to prevent
mal-function.
6.2 Function Code Groups
On the operation panel, press
and then or , and you can view the
function code groups. The function code groups are classied as follows:
F0 Basic parameters F9 Time parameters
F1 Motor parameters FA Keypad setting parameters
F2 Vector control parameters Fb Door function parameters
F3 Running control parameters FC Protection function parameters
F4 Floor parameters Fd Communication parameters
F5 Input terminal parameters FE Elevator function parameters
