- 170 -
FE-14 Elevator Function Selection 2
Bit Function Description Default
Bit2
Door close
command not
output upon door
close limit
The system stops outputting the door close
command upon door close limit.
0
Bit3 Manual door
When this function is enabled, the system does not
output the door open/close command (electric lock
output still active), and does not detect door open/
close limit.
0
Bit4
Auto reset for
RUN and brake
contactor stuck
If the feedback of the RUN and brake contactors is
abnormal, faults Err36 and Err37 are reported, and
you need to manually reset the system.
With this function, the system resets automatically
after the fault symptom disappears. A maximum of
three auto reset times are supported.
0
Bit5
Slow-down switch
stuck detection
The system detects the state of slow-down switches.
Once detecting that a slow-down switch is stuck,
the system instructs the elevator to slow down
immediately and reports a corresponding fault.
1
Bit10
NO/NC output
selection of
shorting PMSM
stator contactor
Bit10 = 0: NC output contactor
Bit10 = 1: NO output contactor
0
Bit12 Fan/Lamp output
Bit12 = 0: NC output
Bit12 =1: NO output
0
Group Fr: Leveling Adjustment Parameters
Function Code Parameter Name Setting Range Default Unit Property
Fr-00
Leveling
adjustment function
0: Disabled
1: Enabled
0 -
★
This parameter is used to enable the leveling adjustment function.
Function Code Parameter Name Setting Range Default Unit Property
Fr-01 Leveling adjustment record 1
00000–60060
30030 mm ★
Fr-02 Leveling adjustment record 2 30030 mm ★
… …
Fr-08 Leveling adjustment record 8 30030 mm ★
These parameters are used to record the leveling adjustment values. Each parameter
records the adjustment information of two oors, and therefore, 40 oor adjustment records
are supported totally.
The method of viewing the record is shown in the following gure.
