Monarch NICE1000 User Manual

Description of Function Codes NICE1000
new
User Manual
- 144 -
leveling position under the effect of the weighing difference between the car and the
counterweight. This function can also be used during normal elevator running to enhance
the safety.
Function Code Parameter Name Setting Range Default Unit Property
F7-04 Y4 function selection 06–99 00 -
★
F7-05 Y5 function selection 06–99 00 -
★
F7-06 Y6 function selection 06–99 06 -
★
... ... ... ... -
★
F7-27 Y27 function selection 06–99 00 -
★
The output functions are as follows:
00: Invalid
06: Door 1 open output 07: Door 1 close output 08: Door 2 open output
09: Door 2 close output 10: Low 7-segment a display output
11: Low 7-segment b display output 12: Low 7-segment c display output
13: Low 7-segment d display output 14: Low 7-segment e display output
15: Low 7-segment f display output 16: Low 7-segment g display output
17: Up arrow display output 18: Down arrow output
19: Minus sign display output 20: Returning to base oor at re emergency
21: Buzzer output 22: Overload output 23: Arrival gong output
24: Full-load output 25: Inspection output 26: Fan/Lamp output 2
27: Shorting door lock circuit contactor output
28: BCD/Gray code/7-segment high-bit output
29: Controller normal running output 30: Electric lock output
31: Reserved 32: Emergency evacuation at power failure
33: Forced door close 1 34: Forced door close 2
35: Faulty state 36: Up signal
37: Medical sterilization output 38: Non-door zone stop output
39: Non-service state output 40: Reserved
41: High 7-segment a display output 42: High 7-segment b display output
43: High 7-segment c display output 44: High 7-segment d display output
45: High 7-segment e display output 46: High 7-segment f display output
47: High 7-segment g display output 48–99: Reserved
