Network Setup 4-61
4. To view WLAN statistics in greater detail, select a WLAN and click the Statistics button. For more
information, see Viewing WLAN Statistics in Detail on page 4-61.
5. To view WLAN statistics in a graphical format, select a WLAN and click the Graph button. For more
information, see Viewing WLAN Statistics in a Graphical Format on page 4-63.
6. To view WLAN packet data rates and retry counts, select a WLAN and click the Switch Statistics
button. For more information, see Viewing WLAN Switch Statistics on page 4-64.
4.5.2.1 Viewing WLAN Statistics in Detail
When the WLAN Statistics screen does not supply adequate information for an individual WLAN, the
Details screen is recommended for displaying more granular information for a single WLAN. Use this
information to discern if a WLAN requires modification to meet network expectations.
To view detailed statistics for a WLAN:
1. Select a Network > Wireless LANs from the main menu tree.
2. Click the Statistics tab.
3. Select a WLAN from the table displayed in the Statistics screen. and click the Details button. v
The Details screen displays the WLAN statistics of the selected WLAN.
Avg BPS Displays the average bit speed in Mbps for the selected WLAN. This includes all
packets sent and received.
% Non-UNI Displays the percentage of the total packets for the selected WLAN that are non-
unicast packets. Non-unicast packets include broadcast and multicast packets.
Retries Displays the average number of retries for all MUs associated with the selected
WLAN.
NOTE: When using mesh-enabled WLAN statistics, no statistics are shown. This is
because WLAN statistics are generated by mobile unit traffic for that particular WLAN. In
a mesh configuration, there are typically no mobile units associated and therefore no
statistical information to display.
