7-4 Motorola RF Switch System Reference Guide
3. Click the Apply button to save changes made to the screen since the last saved configuration.
4. Click the Revert button to revert the screen back to its last saved configuration. Changes made since the
contents of the screen were last applied are discarded.
7.3 Configuring SNMP Access
Use the SNMP Access menu to view and configure existing SNMP v1/v2 and SNMP v3 values and their
current access control settings. You can also view the SNMP V2/V3 events and their current values. The
SNMP Access window consists of the following tabs:
• Configuring SNMP v1/v2 Access
• Configuring SNMP v3 Access
• Accessing SNMP v2/v3 Statistics
• Message Parameters
HTTPS Trustpoint Use the Trustpoint drop-down menu to select the local or default trustpoint used
with a HTTPS session with the switch. For information on creating a new
certificate, see Creating Server Certificates on page 6-108.
Enable FTP Select this checkbox to enable FTP access to the switch. File Transfer Protocol (FTP)
is the language used for file transfers across the Web. This setting is disabled by
default.
Port Displays the port number used for the FTP session with the switch (if using FTP).
Username Displays the read-only name of the user whose credentials are used for the FTP
session.
Password If FTP is enabled, a password is required (for the user specified in the
Username
field) to use the switch with the FTP interface.
Root Dir. Define the root directory where the FTP server is located (if using FTP). Click the
Magnifying Glass icon to display a Select Directory File screen useful in
selecting the root directory. If necessary a new directory folder can be created.
Enable SSHv2 Select this checkbox to enable SSH version 2 access to the switch. Secure Shell
(SSH) is a program designed to perform a number of functions, such as file transfer
between computers, command execution or logging on to a computer over a
network. It is intended to do these tasks with greater security than programs such
as Telnet or FTP. This setting is enabled by default.
Port Define the port number used for the SSH session with the switch.
RSA Key Pair Use the RSA Key Pair drop-down menu to select a public/private key pair used for
RSA authentication. The default setting is “default_ssh_rsa_key”
NOTE: You cannot establish a SSH session with the switch when a RSA Key with a length
of 360 is associated with the SSH-Server.
CAUTION: Your system must be running Sun JRE version 1.5.x (or higher) or Mozilla for
the switch Web UI to be used with the SNMP interface.
