Motorola RFS Series System Reference Guide

6-102 Motorola RF Switch System Reference Guide
6. Click the Apply button to save the changes made to within the screen.
7. Click the Revert button to cancel any changes made within the screen and revert back to the last saved
configuration.
6.8.5 Configuring Radius Users
Refer to the Users tab to view the current set of users and groups assigned for the Radius server. The Users
tab is employed when Local is selected as the Auth Data Source within the Authentication & Accounting
tab.
To define the Radius user permissions for switch access:
1. Select Security > Radius Server from the main menu.
2. Select the Users tab.
Domain Admin
Password
Enter the Administrator User password
LDAP Agent Retry
Timeout
Defines the time interval after which the LDAP Agent will try to reconnect with the
LDAP server if the previous join attempt had failed.
LDAP Server Dead
Period
This is a period in seconds for which the RADIUS server does not attempt any
connection with the LDAP server after the LDAP server was found to be
unavailable.
NOTE: Administrator Username and Administrator User password are required for the
switch (which runs radius server) to become part of the Windows domain of which the
Active Directory Server is part of.
NOTE: The same configuration is supported for the Secondary LDAP agent of the
Secondary LDAP server also.

Motorola RFS Series Specifications

General

Brand	Motorola
Model	RFS Series
Category	Switch
Language	English
