5-68 Motorola RF Switch System Reference
Once SOLE has been enabled MUs found by the locationing engine will be displayed in the Located MUs
table at the bottom of the page. For each located MU the following information is displayed:
5.8.5 Configuring Aeroscout Parameters
To configure the switch to work with an external Aeroscout RTLS engine:
1. .Services > RTLS from the main menu tree.
2. Select the Aeroscout tab.
3. Check the Enable checkbox to globally enable Aeroscout RTLS support on the switch.
This takes effect immediately when the box is checked.
MAC Lists the MAC Addresses of all MUs which have been located by the switch.
Location:
X Coordinate
Displays the value of the X Coordinate for each located MU. The X coordinate is
relative to the origin point of 0,0 in the upper left corner of the site map.
Location:
Y Coordinate
Displays the value of the Y Coordinate for each located MU. The Y coordinate is
relative to the origin point of 0,0 in the upper left corner of the site map.
Timestamp Displays the last time for each MU that its location was computed by the switch.
Zone Lists the last known zone for each located MU. Zone configuration can be defined
using the CLI interface only. When no zones are configured, the switch defaults
the entire site to Zone 0.
NOTE: Zone configuration can be defined using the CLI interface only. For information on Zone
Configuration please see the Motorola RF Switch CLI Reference.
