Network Setup 4-85
4. When using clustering and the Cluster GUI feature is enabled, a pull-down menu will be available to
select which cluster members’ MUs are displayed. To view MUs from all cluster members, select All
from the pull-down menu. To view MUs from a specific cluster member, select that member’s IP address
from the pull-down menu.
5. To add a MAC address to MU association, click the Add button. For more information on adding an
association, see MAC Naming of Mobile Units.
6. To remove a MAC Name association, select the item from the table and click the Delete button.
7. If changes have been made to the MU table, click the Apply button to save the changes to the running
configuration.
4.6.2.1 MAC Naming of Mobile Units
To configure Mobile Unit settings:
1. Select Network > Mobile Units from the main menu tree.
2. Click the Configuration tab.
3. Enter the MAC Address and MAC Name for the MU being added to the list:
4. Click OK to use the changes to the running configuration and close the dialog.
5. Click Cancel to close the dialog without committing updates to the running configuration.
4.6.3 Viewing MU Statistics
The Statistics screen displays read-only statistics for each MU. Use this information to assess if
configuration changes are required to improve network performance. If a more detailed set of MU statistics
is required, select an MU from the table and click the Details button.
To view MU statistics details:
1. Select Network > Mobile Units from the main menu tree.
MAC Address Each MU has a unique Media Access Control (MAC) address through which it is
identified. This address is burned into the ROM of the MU.
MAC Name The MAC Name is a user-created name used to identify individual mobile unit
MAC Addresses with a user-friendly name.
NOTE: The RFS6000 supports a maximum of 4096 MUs. The RFS7000 supports 8192
MUs.Enter RFS4000 statistics here.
