Network Setup 4-77
4. Map the selected list item with as many WLANs as needed (be selecting the WLAN’s checkbox). Use the
Select All button to associate each WLAN with the selected list item.
5. To remove the WLAN Mappings, select the Deselect All button to clear the mappings.
6. Refer to the Status field for a display of the current state of the requests made from the applet. Requests
are any “SET/GET” operation from the applet. The Status field displays error messages if something
goes wrong in the transaction between the applet and the switch.
7. Click OK to save and add the new configuration and close the dialog window.
8. Click Cancel to close the dialog without committing updates to the running configuration.
4.5.6 NAC Configuration Examples Using the Switch CLI
The following are NAC include list, exclude list, and WLAN configuration examples using the switch
CLI interface:
4.5.6.1 Creating an Include List
Since few devices require NAC, Motorola recommends using the "bypass-nac-except-include-list" option.
Refer to the commands below to create a NAC Include List:
1. Create a NAC include list.
RF Switch (config-wireless) #client include-list Desktop
RF Switch (config-wireless-client-list) #
2. Add a host entry to the include list. This adds a specified MAC entry/MAC range into the client’s include
list.
RF Switch(config-wireless-client-list) #station pc1 AA:BB:CC:DD:EE:FF
RF Switch(config-wireless-client-list) #
3. Associate the include list to a WLAN. This adds the client’s include list into the WLAN.
RF Switch(config-wireless-client-list) #wlan 1
RF Switch(config-wireless-client-list) #
4.5.6.2 Creating an Exclude List
To create a NAC Exclude List:
1. Define the NAC include list.
RF Switch(config-wireless) #client exclude-list Desktop
RF Switch(config-wireless-client-list) #
2. Add a host entry into the exclude list.
RF Switch(config-wireless-client-list) #station pc10 AB:BC:CD:DE:EF:FA
RF Switch(config-wireless-client-list) #
NOTE: The instance changes from
(config-wireless) to (config-wireless-
client-list)
.
