Motorola RFS Series - Power over Ethernet (Poe)

Switch Information 3-21
• Input Bytes
• Input Pkts Dropped
• Output Pkts Total
• Output Pkts Error
• Input Pkts Total
• Input Pkts Error
• Output Pkts NUCast
• Input Pkts NUCast
• Output Bytes
• Output Pkts Dropped
3. Display any of the above by selecting the checkbox associated with it.
4. Click on the Close button to exit out of the screen.
3.2.4 Power over Ethernet (PoE)
The RFS6000 switch supports 802.3af Power over Ethernet (PoE) on each of its eight ge ports. The PoE screen
allows users to monitor the power consumption of the ports and configure power usage limits and priorities
for each of the ge ports.
To view the PoE configuration:
1. Select Switch > Ports from the main menu tree.
NOTE: You are not allowed to select (display) more than four parameters at any given
time.
SWITCH NOTE: Power over Ethernet is supported on the RFS6000 and RFS4000
switches.
