Motorola RFS Series System Reference Guide

Network Setup 4-149
2. Click the Configuration tab.
3. Click the Syslog Config button.
4. Check the Enable Logging to Syslog Server option to enable logging to an external Syslog server.
Select the logging level from the drop-down menu.
5. Enter the IP address of the external Syslog server in the Syslog Server IP Addr field.
6. Click the OK button.
4.9.3.3 Configuring LLDP Settings for Access Port
Link Layer Discovery Protocol (LLDP) is a protocol that enables devices to advertise their capabilities and
media-specific configuration. LLDP provides a standard method of discovering and representing the physical
network connections of a given network management domain.
1. Check the Enable LLDP checkbox to enable or disable the transmission of LLDP advertisements.
2. Enter the refresh interval value in the Refresh Interval field. This parameter indicates the interval at
which LLDP frames are transmitted on behalf of this LLDP agent.
3. Enter the holdtime multiplier value in the Holdtime Multiplier field. This parameter is a multiplier on
the ‘Refresh Interval’ that determines the actual TTL value used in an LLDPDU.
4.9.4 Viewing Sensor Information
Use the Sensor tab to view information on AP300s configured as sensors and if needed revert them to
Access Ports.
To view existing Sensor information:
1. Select Network > Access Port from the main menu tree.
NOTE: As of now, these settings apply only to AP650.
