Motorola RFS Series System Reference Guide

Network Setup 4-171
2. Select the Configuration tab.
The Configuration tab displays the following information:
4.12.1.1 Configuring an Internal Hotspot
Using the Internal option means the user develops the hotspot using the internal Web server. The HTML
pages are pre-created to collect login credentials through Login.htm, to send them to a RADUIS server, and
display a Welcome.htm or a Faliure.htm depending on the result of the authentication attempt.The terms of
usage for the hotspot is also configurable using the Terms html page.
To create a hotspot maintained by the switch’s own internal resources:
Vlan Index Enter a Vlan index between 1 and 4094.
Enable Click the Enable button to enable a hotspot.
Vlan Index The Vlan index on which the hotspot is enabled.
Primary RADIUS Server IP/
Port
This is the IP address of the Primary RADIUS server and the port on which the
Primary RADIUS server is listening.
Secondary RADIUS Server
IP/Port
This is the IP address of the Secondary RADIUS server and the port on which the
Secondary RADIUS Server is listening.
Edit Click the Edit button to configure the internal and the external hotspots as well as
to configure the RADIUS Server.
Delete Click the Delete button to delete an enabled hotspot entry.
NOTE: When using an internal hotspot, ensure that traffic can pass on TCP port 444
between the switch’s internal Web server and the hotspot clients.
