Switch Information 3-35
1. Refer to the Source field to specify the source file. Use the From drop-down menu and select Wireless
Switch.
2. Use the Browse button and select a file for transfer.
3. Use the To drop-down menu (within the Target field) and select Server. This defines the transfer location
of the configuration file. Enter the file location marked to store the transferred file.
4. Use the Using drop down-menu to configure whether the log file transfer is conducted using FTP, TFTP,
or SFTP. This field displays the default port for FTP,TFTP, or SFTP. The value in this field can be configured
as required. Enter the IP Address of the server receiving the source configuration. Ensure the IP address
is valid or risk jeopardizing the success of the file transfer. Enter the User ID credentials required to
transfer the configuration file from an FTP server.
5. Enter the Password required to send the configuration file from an FTP server.
6. Specify the appropriate Path name to the target directory on the server. The target options are different
depending on the target selected.
7. Click the Transfer button to complete the file transfer. The Message section in the main menu area
displays the file transfer message.
8. Click Abort at any time during the transfer process to abort the file transfer.
3.5.1.3 Transferring a File from a Server to a Wireless Switch
To transfer a file from a Server to the switch:
SWITCH NOTE: On the RFS7000, users can also transfer files using USB or Compact
Flash. On the RFS6000, users can also transfer files using USB. On the RFS4000, users can
also transfer the files using USB, or PCI Express.
