Native Instruments MASCHINE MK3 User Manual

You can select multiple Sound slots and quickly assign them all to a particular Link
group at once!
To assign the selected Sound(s) to a Link group and set its/their Link mode (Master or Slave),
do the following:
1. Click the Pad View button above the Sound List in the Pattern Editor to show the Pad
view for the focused Group.
2. In the Link section click the Group value and select the desired group 1–8 from the list or
choose None (default setting) to remove the Sound from its current Link group.
3. In the same Link section click the Mode value (Master or Slave) to switch the Sound be-
tween Master (default setting) and Slave mode.
A Link group makes sense only if more than one pad/Sound are assigned to it!
Adjusting the Link Parameter for Multiple Sounds with different Link Values
► Click the MULTI label next to Link and select the desired value from the list to set all
selected Sounds to that same Link group. This also applies to the Master/Slave setting
next to it.
Playing on the Controller
Adjusting the Pads
MASCHINE - Manual - 236

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
